Marienberg Devices VC Oscillator B

444 € 1 981,01 PLN zawiera podatek VAT · Darmowa wysyłka
Na tel./ email

Szczegóły

Voltage Controlled OscillatorThe VCO B is an inexpensive, small oscillator with triangle, sawtooth, ramp and pulse waveforms. For modulation, there are inputs for FM (exponential), sync and pulse width modulation.

  • Analog, high-quality oscillator with triangle, sawtooth, ramp and pulse waveforms
  • Frequency range: 32 Hz to 8 kHz
  • LFO mode: 0.22 Hz to 35.5 Hz
  • SUB mode: 0.01 Hz to 2.65 Hz
  • Voltage range per input 0 to 10 V
  • Power Consumption: 90 mA
  • Connectors 6,3 mm mono jack
  • Dimensions: 222.25 x 50.8 x 40 mm
  • Weight: 274 g
  • Developed and handmade in Germany
  • Can only be operated with Marienberg Devices power supply units!
